USB 10 Channels ADC 12Bit DAQ Module

Description

The USB 10 Channels ADC 12Bit DAQ Module is a versatile and high-performance data acquisition module designed for a wide range of applications, including electronics projects, industrial automation, and DIY projects. With its robust features and reliable performance, it is an excellent choice for both hobbyists and professionals.

Key Features:

• High Performance: Equipped with the STM32F103C8T6 main control chip, providing robust processing power and high accuracy.
• Multiple Channels: Supports 10 single-ended analog input channels, allowing for simultaneous data acquisition from multiple sources.
• High Resolution: Offers a 12-bit resolution (4096 levels), ensuring precise and accurate data conversion.
• USB and UART Interface: Features an onboard CH340 serial port to USB chip for easy data transfer to a PC, and a reserved UART serial communication interface for connection to microcontrollers.
• Wide Voltage Range: Supports a sampling voltage input range of 0-3.3V, making it suitable for various applications.
• Compact Design: Small and lightweight design, making it easy to integrate into various projects.

Specifications:

• Main Control Chip: STM32F103C8T6
• Analog Input Channels: 10 single-ended input channels
• Resolution: 12-bit (4096 levels)
• Sampling Voltage Input Range: 0-3.3V
• Power Supply Voltage: 5V/3.3V
• Sample Time: 500ms
• Default Baud Rate: 115200
• Communication Interface: USB (CH340) and UART
• PCB Size: 51mm x 35mm

Applications:

• Electronics Projects: Ideal for data acquisition in various electronic circuits and components.
• Industrial Automation: Suitable for industrial applications that require precise and reliable data acquisition.
• DIY Projects: Perfect for DIY enthusiasts working on various electronics and data acquisition projects.
• Educational Use: Great for students and educators learning about data acquisition and analog-to-digital conversion.

The USB 10 Channels ADC 12Bit DAQ Module is a versatile and reliable data acquisition module that can enhance the performance of your projects. Whether you’re building an electronics project, an industrial system, or a DIY creation, this module offers the features and reliability you need.

Package:

1xUSB 10 Channels ADC 12Bit DAQ Module
