TTL Serial Cable Adapter

Description

FTDI based USB to TTL Serial Cable are designed using the the standard FT232BL chipset.
The cables provide a fast, simple way to connect devices with a TTL level serial interface to USB.

The cables are available with a 6-way SIL, 0.1″ connectorTTL levels is 3.3V
The TTL-232R cables are a family of USB to TTL serial UART converter cables incorporating FTD’s FT232BL USB to SerialUART interface IC device which handles all the USB signalling and protocols.

The cables provide a fast, simple way to connectdevices with a TTL level serial interface to USBEach TTL-232R cable contains a small internal electronic circuit board, utilising the FT232BL, which is encapsulated into the USBconnector end of the cable. The other end of the cable comes with a selection of different connectors supporting various applications .

Cables are FCC, CE, RoHS compliant and are available at TTL levels 3.3V.
Cables are available with either a 6-way SIL,0.1″pitch connector, a 3.5mmAudio Jack, an 8 way, keyed 2mmpitch connector(intended for use with VMUSIC2 or VDRIVE2) or bare, tinned wire ended connections

The USB side of the cable is USB powered and USB 2.0 full speed compatible.
Each cable is1.0m long and supports a data transfer rate up to 3 Mbaud

Red wire: 5V
Black wire: GND
White wire: RXD
Green wire: TXD
Yellow wire: RTS
Blue wire: CTS

Package Included:
1PCS* FTDI FT232BL USB to Serial adapter module USB TO TTL RS232 for Arduino Cable 6Pin
