Raspberry Pi 3 Model A+

Description

The Raspberry Pi 3 Model A+ is a compact and powerful development board designed for various applications, including education, prototyping, and IoT projects. It offers significant improvements in processor speed, wireless performance, and connectivity compared to its predecessors.

Specifications:

• Processor: Broadcom BCM2837B0, Cortex-A53 (ARMv8) 64-bit SoC @ 1.4GHz
• Memory: 512MB LPDDR2 SDRAM
• Wireless Connectivity: 2.4GHz and 5GHz IEEE 802.11.b/g/n/ac wireless LAN, Bluetooth 4.2/BLE
• GPIO: Extended 40-pin GPIO header
• Ports:
  • 1 x Full-size HDMI
  • 1 x USB 2.0 port
  • 1 x CSI camera port for connecting a Raspberry Pi Camera
  • 1 x DSI display port for connecting a Raspberry Pi Touch Display
  • 1 x 4-pole stereo output and composite video port
• Storage: MicroSD card slot for loading operating system and storing data
• Power Supply: 5V/2.5A DC via Micro USB connector
• Operating Temperature: 0°C to +50°C
• Dimensions: 65mm x 56mm x 17mm
• Weight: 29g

Features:

• High-Performance Processing: Equipped with a powerful quad-core processor, providing fast processing speeds for demanding applications.
• Integrated Wireless Connectivity: Built-in dual-band Wi-Fi and Bluetooth for seamless internet access and communication.
• Compact and Portable Design: Small form factor, making it ideal for on-the-go projects and applications.
• Versatile Application Options: Suitable for a variety of applications, including education, prototyping, and IoT projects.
• User-Friendly Design: Pre-soldered GPIO header and easy-to-use interface, making it ideal for beginners.

Pinout Diagram:

Here’s the pinout diagram for the Raspberry Pi 3 Model A+:

How to Use:

• Prepare the MicroSD Card: Download and install the Raspberry Pi OS on a microSD card.
• Insert the MicroSD Card: Insert the prepared microSD card into the microSD card slot on the Raspberry Pi 3 Model A+.
• Connect Peripherals: Connect a keyboard, mouse, and monitor to the board using the appropriate adapters and cables.
• Power the Board: Connect a 5V power supply to the Micro USB power port.
• Access the OS: Once powered on, the Raspberry Pi OS will boot up, and you can start using the board for your projects.

Package:

1xRaspberry Pi 3 Model A+
