FNIRSI LCR-P1

Description

Item Description: The FNIRSI® LCR-P1 is an indispensable, highly versatile, and intelligent multifunction component tester designed for every electronics enthusiast, engineer, and repair technician. This compact device automatically identifies and tests a wide array of electronic components, including resistors, capacitors, inductors, diodes, transistors (NPN, PNP, MOSFETs, JFETs), SCRs, and triacs. With its automatic recognition of component type and pinout, combined with precise measurements of LCR values and crucial ESR (Equivalent Series Resistance) for capacitors, the LCR-P1 simplifies component debugging, sorting, and fault diagnosis, making it an essential tool for circuit development and repair.

Key Features:

• Automatic Component Identification: Intelligently recognizes the type of component (resistor, capacitor, inductor, diode, transistor, etc.) upon connection.
• Automatic Pinout Detection: Automatically determines and displays the pin configuration (e.g., EBC for a bipolar transistor).
• Comprehensive LCR Measurement: Accurately measures Inductance (L), Capacitance (C), and Resistance (R).
• ESR Measurement for Capacitors: Crucial for identifying faulty or aged electrolytic capacitors, providing insight into their health.
• Transistor Testing: Identifies NPN, PNP bipolar transistors, N-channel and P-channel MOSFETs, JFETs, and provides hFE (current gain) for bipolars and threshold voltage/gate capacitance for MOSFETs.
• Diode Testing: Measures forward voltage drop and identifies single/dual diodes.
• Thyristor/Triac Detection: Capable of detecting SCRs and Triacs.
• Infrared Decoding: (If applicable for this specific LCR-P1 variant) Some versions might include an IR decoder for remote controls.
• Clear Display: Features a bright and easy-to-read OLED or LCD screen displaying measurement results and component graphics.
• Single Button Operation: Simple and intuitive testing with just one press of a button.
• Battery Powered & Portable: Runs on a built-in rechargeable battery, ideal for on-the-go use.

Specifications:

• Model: FNIRSI® LCR-P1
• Display: 1.44 inch Color  Screen]
• Resistance Measurement Range: 0.01Ω to 50MΩ
• Capacitance Measurement Range: 25pF to 100mF (100,000uF)
• Inductance Measurement Range: 10uH to 1000uH
• ESR Resolution: 0.01Ω
• Transistor Detection: Bipolar (NPN, PNP), MOSFET (N-channel, P-channel), JFET, Diode, SCR, Triac
• Power Supply: Built-in Rechargeable Lithium Battery (e.g., 300mAh)
• Charging Port: USB Type-C
• Test Points: 3 (usually marked T1, T2, T3 or 1, 2, 3)
• Dimensions: Approximately 70 x 60 x 15mm
• Weight: Approximately 50g

Usage: The FNIRSI® LCR-P1 is an invaluable asset for various electronic tasks. It’s perfect for identifying unknown components in your parts bin, quickly checking if a component is faulty during circuit troubleshooting and repair, or verifying component values before soldering. Hobbyists will find it indispensable for building and experimenting with electronics projects, while professional technicians can use it for quick on-site diagnostics and quality control. Its ability to measure ESR makes it particularly useful for repairing power supplies, motherboards, and audio equipment where capacitor degradation is a common issue.

Package Content:

• 1x FNIRSI® LCR-P1 Multifunction Tester Unit
• 1x Set of High-Quality Test Clips/Hooks (e.g., three separate clips for the test points)
• 1x USB Type-C Charging Cable
• 1x User Manual (English)
